Jeep Compass and Renegade: 7" or 8.4" Uconnect Screen? How to Tell Before You Order

UAM is not one screen. It is the sales code for the Uconnect 4/4C hardware family used in the Jeep Compass and Renegade, and that family includes two different screen sizes: a 7-inch display and an 8.4-inch display. They are not interchangeable, and ordering the wrong one is one of the most common mistakes owners make on these vehicles.

Why the Same Vehicle Can Have Either Size

Compass and Renegade trim levels determine which Uconnect hardware ships from the factory. Lower trims typically use the 7-inch display, while higher trims with additional infotainment features use the 8.4-inch display. Model year alone does not tell you which one you have. A 2019 Compass and a 2019 Renegade can each be built with either screen depending on trim and options.

How to Confirm Which Size You Have

Measure your screen diagonally, corner to corner, before ordering anything. This is the only reliable way to confirm size. Do not rely on trim name alone, since trim lineups and equipment have changed across model years.

If you already have the old screen out of the dash, the part number printed on it will also confirm which assembly you have:

• 7-inch UAM: TDO-WXGA0700K00033-V2 or TDO-WXGA0700K00057-V1
• 8.4-inch UAM: VP2RFP or LA084X02 SL 01

What Each Replacement Covers

7" UAM LCD + Touchscreen Assembly ($199.00): Fits 2017–2021 Jeep Compass and 2018–2021 Jeep Renegade models equipped with the 7" UConnect 4/4C display. Resolves ghost touch, frozen or unresponsive touch, black-and-white vertical lines, partial screen blackout, and bubbling or peeling at the edges.

8.4" UAM LCD + Touchscreen Assembly ($249.00): Fits 2018–2022 Jeep Compass and Renegade models equipped with the 8.4" UConnect 4/4C display. Resolves the same category of failures, plus symptoms tied to the larger unit's added functionality, such as climate controls or audio changing on their own from ghost touch.

Both are complete, pre-bonded LCD and touchscreen assemblies. Neither requires programming or dealer calibration. Both carry a 2-year warranty with a Lifetime upgrade option.

Why Getting This Wrong Is Costly

Because these are precision-fit assemblies, orders placed for the incorrect screen size are not eligible for return once the packaging is opened or the part is installed. Measuring first takes two minutes and avoids paying for a part you cannot use and cannot send back.
